Fully automatic filo dough machine PPS1

1. The produced filo dough is made into paper-thin sheets for pastries and is used to create a variety of desserts and savory items.

2. The filo dough can be used in many ways: layered, folded, rolled, ruffled, and with various fillings.

3. Very thin layers for Baklava (Baklawa), Samosa sheet, Cupcackes, Sweet spring rolls.

Technical data

Model

PPS10220

PPS10240

PPS10270

Laminating rollers

6 couples

6 couples

6 couples

Dough roller width

220 mm

240 mm

270 mm

Filo dough width (Max)

220 mm

240 mm

270 mm

Filo dough thickness (Min)

0.15 mm

0.15 mm

0.15 mm

Production capacity

adjustable

adjustable

adjustable

External dimension

3000X650X1260 mm

3000X670X1260 mm

3000X700X1260 mm

Machine weight

500 kg

520 kg

540 kg

Technical data

Model

PPS10290

PPS10340

PPS10400

Laminating rollers

6 couples

6 couples

6 couples

Dough roller width

290 mm

340 mm

400 mm

Filo dough width (Max)

290 mm

340 mm

400 mm

Filo dough thickness (Min)

0.15 mm

0.15 mm

0.15 mm

Production capacity

adjustable

adjustable

adjustable

External dimension

3000X720X1260 mm

3000X770X1260 mm

3000X830X1260 mm

Machine weight

550 kg

590 kg

630 kg

Technical data

Model

PPS10440

PPS10500

PPS10620

Laminating group rollers

6 couples

6 couples

6 couples

Dough roller width

440 mm

500 mm

620 mm

Filo dough width (Max)

440 mm

500 mm

620 mm

Filo dough thickness (Min)

0.15 mm

0.15 mm

0.15 mm

Production capacity

adjustable

adjustable

adjustable

External dimension

3000X870X1260 mm

3000X930X1260 mm

3000X1050X1260 mm

Machine weight

660 kg

710 kg

800 kg

Technical data

Model

PPS10700

PPS10800

PPS10900

Laminating group rollers

6 couples

6 couples

6 couples

Dough roller width

700 mm

800 mm

900 mm

Filo dough width (Max)

700 mm

800 mm

900 mm

Filo dough thickness (Min)

0.15 mm

0.15 mm

0.15 mm

Production capacity

adjustable

adjustable

adjustable

External dimension

3000X1130X1260 mm

3000X1230X1260 mm

3000X1330X1260 mm

Machine weight

860 kg

940 kg

1000 kg

Technical data

Model

PPS11000

PPS11200

PPS11500

Laminating group rollers

6 couples

6 couples

6 couples

Dough roller width

1000 mm

1200 mm

1500 mm

Filo dough width (Max)

1000 mm

1200 mm

1500 mm

Filo dough thickness (Min)

0.15 mm

0.15 mm

0.15 mm

Production capacity

adjustable

adjustable

adjustable

External dimension

3000X1430X1260 mm

3000X1630X1260 mm

3000X1930X1260 mm

Machine weight

1100 kg

1250 kg

1480 kg
